Omschrijving
Share Your 4G LTE Network Take full advantage of your cutting-edge 4G LTE network with the Archer MR400, which can achieve download speeds of up to 150Mbps. The Archer MR400 allows you to share your 4G LTE network with multiple Wi-Fi devices so you can enjoy uninterrupted HD movies, rapid file downloads, and video chats that won't freeze up.
Great Coverage and Dual Band Wi-Fi The 4G LTE router creates a simultaneous dual band Wi-Fi network that can deliver data at speeds of up to 1350Mbps. The two distinct wireless networks, utilizing the 2.4GHz and 5GHz bands, provide optimized performance and minimize signal interference. The incorporation of advanced antennas and the latest wireless technology allows you to enjoy stable connections and incredible coverage.
No Configuration Required With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do insert a SIM card and turn on the Archer MR400. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.
Wi-Fi Where You Need It The Archer MR400 offers unmatched convenience and versatility. The ability to quickly establish powerful wireless networks can be tremendously important. The Archer MR400 is the perfect solution whether you're at home or working in a remote location. Just plug it in to boost on-site productivity and stay connected in a diverse range of environments. From the exhibition center to the RV, the Archer MR400 has you covered.
Available WAN Connection With the inclusion of the WAN/LAN port, the Archer MR400 can also support a wide variety of connection types, including cable, fiber, and DSL modems.
|
Specificaties
USB-poort | | Aantal Ethernet LAN (RJ-45)-poorten | 3 | Aansluiting voor netstroomadapter | |
Breedte | 202 mm | Diepte | 141 mm | Hoogte | 33,6 mm |
Type stroombron | DC | Spanning | 12 | Output current | 1,5 A |
Temperatuur, in bedrijf | 0 - 40 ?C | Temperatuur bij opslag | -40 - 70 ?C | Relatieve luchtvochtigheid, in bedrijf | 10 - 90 procent | Luchtvochtigheid bij opslag | 5 - 90 procent |
DHCP client | | DHCP server | | Ondersteunde netwerkprotocollen | IPv4, IPv6 |
Netwerkstandaard | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n | Port forwarding | | Toegang voor gasten | | Gevoeligheid ontvanger | 5GHz: 11a 54M: -74dBmn11ac HT20: -67dBmn11ac HT40: -64dBmn11ac HT80 : -60dBmn11n HT20: -71dBmn11n HT40: -70dBmn2.4G: 11g 54M: -76dBmn11n HT20: -73dBmn11n HT40: -67dBm | VPN-doorvoer | |
Ondersteunde beveiligingsalgoritmen | 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK | Firewall | | Firewall | DoS, SPI | VPN tunnels quantity | 10 | VPN eigenschappen | PPTP, L2TP, IPSec |
| | Ondersteunt Windows | Windows 2000,Windows 7,Windows 8,Windows 8.1,Windows 98SE,Windows NT,Windows Vista,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 | Ondersteunt Linux | | Ondersteunt Mac-besturingssysteem | |
Wifi-band | Dual-band (2.4 GHz / 5 GHz) | Wifi-standaard | IEEE 802.11ac | WLAN gegevensoverdrachtsnelheid (max) | 867 Mbit/s | Wi-Fi-standaarden | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n | WLAN gegevensoverdrachtsnelheid (eerste band) | 450 Mbit/s | WLAN gegevensoverdrachtsnelheid (tweede band) | 867 Mbit/s |
Web-gebaseerd management | | Reset button | | Quality of Service (QoS) | | WPS Push Button Security | |
Ethernet LAN-eigenschappen |
Ethernet LAN | | Interfacetype Ethernet LAN | Fast Ethernet | Ethernet LAN, data-overdrachtsnelheden | 10,100 Mbit/s |
Inclusief AC-adapter | | Meegeleverde kabels | LAN (RJ-45) | Type verpakking | Box | Snelle installatiehandleiding | |
Soort antenne | Intern & extern | Afneembare antennes | | Zendvermogensgebied | 20 - 23 dBmW | Antennas quantity | 5 |
Producttype | Router om neer te zetten | Kleur van het product | Zwart | Aan/uitschakelaar | |
3G | | 4G | | 2G standaarden | EDGE, GPRS, GSM | 3G standaarden | DC-HSPA+,HSPA,HSPA+,UMTS | 4G standaard | LTE | GSM bands ondersteund | 850,900,1800,1900 MHz | UMTS bands ondersteund | 900,2100 MHz | 4G frequentie ondersteund | 800,900,1800,2100,2600 MHz |
Ethernet WAN | | DSL WAN | | SIM-kaartsleuf | | 3G/4G USB modem compatibiliteit | |
|
|
|
|
